DHP0756G TECO-Westinghouse 75 HP 1200 RPM 405T 230/460V ODP Cast Iron SGR 3-Phase Motor
DHP0756G TECO-Westinghouse 75 HP 1200 RPM 405T 230/460V ODP Cast Iron SGR 3-Phase Motor
DHP0756G TECO-Westinghouse 75 HP 1200 RPM 405T 230/460V ODP Cast Iron SGR 3-Phase Motor
DHP0756G TECO-Westinghouse 75 HP 1200 RPM 405T 230/460V ODP Cast Iron SGR 3-Phase Motor

TECO WESTINGHOUSE

DHP0756G TECO-Westinghouse 75 HP 1200 RPM 405T 230/460V ODP Cast Iron SGR 3-Phase Motor

(No reviews) Write a Review
$6,152.91
SKU DHP0756G
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 75 HP
RPM 1200
Phase Three Phase
Frame 405T
Enclosure ODP
Hertz 60 Hz
Amperage 17286.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 75 hp 1200 RPM, 17286.0 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 405T Frame, 7 1/4 x 2 7/8" Dia. Keyed Shaft
  • Cast Iron Frame, Open Drip Proof
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

General purpose SGR motor for use on pumps, fans, and compressors. The SGR bearing protection ring resists bearing damage by diverting stray electric currents to ground.

Specifications
Voltage 230/460V
Horsepower 75 HP
RPM 1200
Phase Three Phase
Frame 405T
Enclosure ODP
Hertz 60 Hz
Amperage 17286.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
