DJ15P1DM US Motors 15 hp 3600 RPM 3-phase 215JM Frame 208-230/460V (ODP) Close-Coupled Pump Motor
DJ15P1DM US Motors 15 hp 3600 RPM 3-phase 215JM Frame 208-230/460V (ODP) Close-Coupled Pump Motor

US Motors

DJ15P1DM US Motors 15 hp 3600 RPM 3-phase 215JM Frame 208-230/460V (ODP) Close-Coupled Pump Motor

(No reviews) Write a Review
$1,039.60
$928.05
SKU DJ15P1DM
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 15 HP
RPM 3600
Phase Three Phase
Frame 215JM
Enclosure ODP
Hertz 60 Hz
Amperage 36.0/18.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 15 HP 3600 RPM, 40.0-36.0/18.0 amps, 208-230/460V 60hz. 3 Phase.
  • NEMA 215JM Rolled Steel Frame with cast aluminum end-shields, JM stainless steel shaft
  • 1.15 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Open Drip Proof (ODP)
  • Rigid Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drop Proof, Proof, FL78

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 15 HP
RPM 3600
Phase Three Phase
Frame 215JM
Enclosure ODP
Hertz 60 Hz
Amperage 36.0/18.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
!
