UJ15P1DFM US Motors 15 hp 3600 RPM 3-phase 215JM Frame 208-230/460V Close-Coupled Pump Motor

UJ15P1DFM US Motors 15 hp 3600 RPM 3-phase 215JM Frame 208-230/460V Close-Coupled Pump Motor

This US Motors close-coupled pump motor delivers reliable 15 HP power at 3600 RPM, designed for industrial pump applications requiring a direct pump impeller mounting on the motor shaft. It is a suitable replacement for 3-phase motors operating at 208-230/460V and 60 Hz.

Key Specifications

• Horsepower: 15 HP
• RPM: 3600
• Voltage: 208-230/460V
• Amperage: 39.0-36.0/18.0 amps
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: NEMA 215JM Cast Aluminum Frame
• Shaft Dimensions: JM stainless steel shaft
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a removable base for flexible installation and includes an auto overload thermal protection system with Class F insulation for enhanced durability. Its close-coupled design allows the pump impeller to be mounted directly on the shaft, simplifying assembly and reducing alignment issues. The motor is equipped with a totally enclosed fan cooled enclosure to protect against environmental contaminants.

Warranty

1 Year Manufacturer Warranty
