E183A Marathon 15 hp 3600 RPM 3 phase 215JMV Frame (No Base) ODP 230/460V Close Coupled Pump Motor
E183A Marathon 15 hp 3600 RPM 3 phase 215JMV Frame (No Base) ODP 230/460V Close Coupled Pump Motor
E183A Marathon 15 hp 3600 RPM 3 phase 215JMV Frame (No Base) ODP 230/460V Close Coupled Pump Motor
E183A Marathon 15 hp 3600 RPM 3 phase 215JMV Frame (No Base) ODP 230/460V Close Coupled Pump Motor
E183A Marathon 15 hp 3600 RPM 3 phase 215JMV Frame (No Base) ODP 230/460V Close Coupled Pump Motor
E183A Marathon 15 hp 3600 RPM 3 phase 215JMV Frame (No Base) ODP 230/460V Close Coupled Pump Motor
E183A Marathon 15 hp 3600 RPM 3 phase 215JMV Frame (No Base) ODP 230/460V Close Coupled Pump Motor
E183A Marathon 15 hp 3600 RPM 3 phase 215JMV Frame (No Base) ODP 230/460V Close Coupled Pump Motor

Marathon

E183A Marathon 15 hp 3600 RPM 3 phase 215JMV Frame (No Base) ODP 230/460V Close Coupled Pump Motor

(No reviews) Write a Review
$1,881.63
$1,611.15
SKU E183A
UPC 7.23E+11
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 15 HP
RPM 3600
Phase Three Phase
Frame 215JMV
Enclosure ODP
Hertz 60 Hz
Amperage 36.5/18.2 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Rotation Reversible
Duty continuous duty
Adding to cart… The item has been added
Description
  • 15 hp 3600 RPM 215JMV Frame, 36.5/18.2 amps 230/460V 60hz. 3 Phase Motor
  • NEMA 215JMV vertical mount motor having special shaft. Close Coupled Pump Motor, 60 Hz
  • Service Factor: 1.15, Open Drip Proof (ODP) Overload protection: None
  • No base, Reversible rotation, Ball Bearings; Class F Insulation
  • One Year Manufacture Warranty

Close Coupled Pump Motor designed for vertical mounting. Designed for continuous duty service on close Coupled pumps. Motors are suitable for 10:1 VT and 2:1 CT. Wiring diagram on motor name plate. 215TTDWD4022

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 15 HP
RPM 3600
Phase Three Phase
Frame 215JMV
Enclosure ODP
Hertz 60 Hz
Amperage 36.5/18.2 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Rotation Reversible
Duty continuous duty
!
