E40S1HZ Nidec 40 hp 3600 RPM 200V 3-phase 160LCS Frame Oil Submersible Elevator Motor
E40S1HZ Nidec 40 hp 3600 RPM 200V 3-phase 160LCS Frame Oil Submersible Elevator Motor
E40S1HZ Nidec 40 hp 3600 RPM 200V 3-phase 160LCS Frame Oil Submersible Elevator Motor
E40S1HZ Nidec 40 hp 3600 RPM 200V 3-phase 160LCS Frame Oil Submersible Elevator Motor

Nidec

E40S1HZ Nidec 40 hp 3600 RPM 200V 3-phase 160LCS Frame Oil Submersible Elevator Motor

(No reviews) Write a Review
$2,051.60
$1,831.38
SKU E40S1HZ
Availability Please email for availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 40 HP
RPM 3600
Phase Three Phase
Frame 160LCS
Hertz 60 Hz
Amperage 119 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Foot

CURRENTLY OUT OF STOCK

Description
  • 40 HP 3600 RPM, 119 amps, 200V 60 Hz. 3 Phase.
  • NEMA 160LCS Zinc Plated Steel Frame, 32 mm LCS shaft
  • 1.0 Service Factor, Class F insulation
  • Reversible Rotation, 112" leads
  • Horizontal Foot Mount, Single Ball Bearing Design to fit most Allweiler and IMO pumps

Motor designed for replacing elevator motors on low rise buildings with Z-flanged motors from Allweiler Pumps (SUB 140, 210, 280) and IMO Pumps (3SIC-187, 3SIC-200, 3SIC-218, 3SIC-250, 4SIC-275). Also used on L32 Flanged motors from Allwieler (SUA 140, 210, 280, 440)  1 Year Manufacture Warranty. J225

Specifications
Voltage 200V
Horsepower 40 HP
RPM 3600
Phase Three Phase
Frame 160LCS
Hertz 60 Hz
Amperage 119 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Foot
!
