EC13 Nidec 2 hp 3600 RPM 208-230V 56C Frame (No Base) TEFC 1-Phase Electric Motor
EC13 Nidec 2 hp 3600 RPM 208-230V 56C Frame (No Base) TEFC 1-Phase Electric Motor
EC13 Nidec 2 hp 3600 RPM 208-230V 56C Frame (No Base) TEFC 1-Phase Electric Motor
EC13 Nidec 2 hp 3600 RPM 208-230V 56C Frame (No Base) TEFC 1-Phase Electric Motor

Nidec

EC13 Nidec 2 hp 3600 RPM 208-230V 56C Frame (No Base) TEFC 1-Phase Electric Motor

(No reviews) Write a Review
$921.15
$822.48
SKU EC13
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 2 HP
RPM 3600
Phase Single Phase
Frame 56C
Enclosure TEFC
Hertz 50/60 Hz
Amperage 9.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting C-Face
Adding to cart… The item has been added
Description
  • 2 hp 3600 RPM, 9.6-9.0 amps 208-230 Volts 50/60 Hz Capacitor Start Motor
  • NEMA 56C frame Keyed Shaft 5/8" Diameter x 1 7/8" Long
  • Service Factor: 1.15, Overload protection = Auto
  • Face Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

Commercial C-Face pump motor can be used for many applications.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. T063CPF1450014J

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 2 HP
RPM 3600
Phase Single Phase
Frame 56C
Enclosure TEFC
Hertz 50/60 Hz
Amperage 9.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting C-Face
!
