EC2002B Nidec 2 hp 3600 RPM 115/208-230V 56C Frame (Rigid Base) ODP 1-Phase Electric Motor

SKU:
EC2002B
Weight:
34.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $609.00
Now: $544.10
Adding to cart… The item has been added
  • 2 hp 3600 RPM, 19.6/10.7-9.8 amps 115/208-230 Volts 50/60 Hz Capacitor Start / Capacitor Run Motor
  • NEMA 56C Frame, Keyed Shaft 5/8" Diameter x 1 7/8" Long
  • Service Factor: 1.15, Overload protection = Auto
  • Base or Face Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

Commercial C-Face pump motor can be used for many applications. Wiring diagram on motor name plate. ODP = Open Drip Proof. T063CLS1400013J
