EJM202B Nidec 2 hp 3600 RPM 1-phase 145JM Frame 115/208-230V ODP Close-Coupled Pump Motor

EJM202B Nidec 2 hp 3600 RPM 1-phase 145JM Frame 115/208-230V ODP Close-Coupled Pump Motor

The EJM202B is a 2 horsepower, single-phase pump motor designed for reliable performance in various industrial and HVAC applications. It is often interchangeable with Century P124 motors, making it a versatile replacement option for existing setups requiring a close-coupled pump motor.

Key Specifications

• Horsepower: 2 HP
• RPM: 3600
• Voltage: 115/208-230V, 60 Hz
• Amperage: 19.6 / 10.7-9.8 amps
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 145JM Rolled Steel Frame
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base and C-face mounting, facilitating straightforward installation and secure attachment. The close-coupled design means the pump impeller mounts directly on the motor shaft, reducing alignment issues and simplifying maintenance. The motor includes a JM steel shaft and Class B insulation, but does not have built-in thermal protection.

Warranty

1 Year Manufacturer Warranty
