EU0502 Nidec 1/2 hp 3600 RPM 115/208-230V 56J Frame (No Base) ODP 1-Phase Electric Motor

EU0502 Nidec 1/2 hp 3600 RPM 115/208-230V 56J Frame (No Base) ODP 1-Phase Electric Motor

SKU:
EU0502
Weight:
19.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $280.00
Now: $250.10
Adding to cart… The item has been added
  • 1/2 hp 3600 RPM, 8.2/4.2-4.1 amps 115/208-230 Volts 50/60 Hz Capacitor Start Motor
  • NEMA 56J Frame, Shaft 5/8" Diameter x 1 7/8" Long with threaded tip
  • Service Factor: 1.15, Overload protection = Auto
  • Base Mount, Ball Bearings, Class B Insulation, CCW drive end
  • 1 Year Manufacture Warranty

Commercial C-Face pump motor can be used for many applications. Wiring diagram on motor name plate. ODP = Open Drip Proof. C055JZN4768013J

!
