EU0502B Nidec 1/2 hp 3600 RPM 115/208-230V 56J Frame (Rem Base) ODP 1-Phase Electric Motor
EU0502B Nidec 1/2 hp 3600 RPM 115/208-230V 56J Frame (Rem Base) ODP 1-Phase Electric Motor
EU0502B Nidec 1/2 hp 3600 RPM 115/208-230V 56J Frame (Rem Base) ODP 1-Phase Electric Motor
EU0502B Nidec 1/2 hp 3600 RPM 115/208-230V 56J Frame (Rem Base) ODP 1-Phase Electric Motor

Nidec

EU0502B Nidec 1/2 hp 3600 RPM 115/208-230V 56J Frame (Rem Base) ODP 1-Phase Electric Motor

(No reviews) Write a Review
$327.75
$249.95
SKU EU0502B
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/208/230V
Horsepower 1/2 HP
RPM 3600
Phase Single Phase
Frame 56J
Enclosure ODP
Hertz 50/60 Hz
Amperage 4.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting C-Face
Adding to cart… The item has been added
Description
  • 1/2 hp 3600 RPM, 8.2/4.0-4.1 amps 115/208-230 Volts 50/60 Hz Capacitor Start Motor
  • NEMA 56J Frame, Shaft 5/8" Diameter x 1 7/8" Long with threaded tip
  • Service Factor: 1.15, Overload protection = Auto
  • C-Face or Removable Base Mount, Ball Bearings, Class B Insulation, CCW drive end
  • 1 Year Manufacture Warranty

Commercial C-Face pump motor can be used for many applications. Wiring diagram on motor name plate. ODP = Open Drip Proof. C063HLL5020013J

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/208/230V
Horsepower 1/2 HP
RPM 3600
Phase Single Phase
Frame 56J
Enclosure ODP
Hertz 50/60 Hz
Amperage 4.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting C-Face
!
