EU11 Nidec 2 hp 3600 RPM 208-230V 56J Frame (Rem Base) TEFC 1-Phase Electric Motor
EU11 Nidec 2 hp 3600 RPM 208-230V 56J Frame (Rem Base) TEFC 1-Phase Electric Motor
EU11 Nidec 2 hp 3600 RPM 208-230V 56J Frame (Rem Base) TEFC 1-Phase Electric Motor
EU11 Nidec 2 hp 3600 RPM 208-230V 56J Frame (Rem Base) TEFC 1-Phase Electric Motor

Nidec

EU11 Nidec 2 hp 3600 RPM 208-230V 56J Frame (Rem Base) TEFC 1-Phase Electric Motor

(No reviews) Write a Review
$932.65
$832.49
SKU EU11
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 2 HP
RPM 3600
Phase Single Phase
Frame 56J
Enclosure TEFC
Hertz 50/60 Hz
Amperage 9.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting C-Face
Adding to cart… The item has been added
Description

    2 hp 3600 RPM, 9.6-9.0 amps 208-230 Volts 50/60 Hz Capacitor Start Motor
    NEMA 56J Frame, Shaft 5/8" Diameter x 1 7/8" Long plus threaded tip
    Service Factor: 1.15, Overload protection = Auto
    Face or Removable Base Mount, Ball Bearings, Class B Insulation, CW lead end
    1 Year Manufacture Warranty

Commercial C-Face pump motor can be used for many applications.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. T063CPK1454013J

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 2 HP
RPM 3600
Phase Single Phase
Frame 56J
Enclosure TEFC
Hertz 50/60 Hz
Amperage 9.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting C-Face
!
