FE6001F 5-5/8" Diameter Condenser Fan Motor 1/3-1/5HP

FE6001F 5-5/8" Diameter Condenser Fan Motor 1/3-1/5HP

The FE6001F is a durable condenser fan motor designed for HVAC applications, offering reliable performance with energy-efficient operation. It serves as a direct replacement for various models including 5464, D2826, 3469, and 5kcp39jfac23, making it suitable for multiple condenser fan setups.

Key Specifications

• Horsepower: 1/3 - 1/5 HP
• RPM: 825
• Voltage: 208-230 V
• Amperage: 1.9 - 1.2 A
• Frame / Diameter: 48 Frame / 5-5/8" Diameter
• Shaft Dimensions: 1/2" x 6.5" with Double Flat
• Rotation: Reversible
• Bearings: Ball Bearings
• Enclosure: TEAO (Totally Enclosed Air Over)

Product Features & Fitment

This motor features a permanent split capacitor (PSC) design with resilient rings on the blower motor and extended thru bolts for enhanced durability. It includes a 370V capacitor; however, for 208V operation, a 10DV capacitor is recommended, and for 230V, a 7.5DV capacitor should be used. The motor is equipped with Rheem mounting holes in the shell, an automatic protector, Class B insulation, and is rated for continuous duty at 60 Hz and 60°C ambient temperature. It comes with 48" leads and supports two-speed operation.

Cross Reference

• 5464 D2826 3469 5kcp39jfac23
