FF15E1DV Nidec 15 hp 3600 RPM 3-phase 215JP Frame 208-230/400V ODP Vertical Close-Coupled Fire Pump Motor
FF15E1DV Nidec 15 hp 3600 RPM 3-phase 215JP Frame 208-230/400V ODP Vertical Close-Coupled Fire Pump Motor
FF15E1DV Nidec 15 hp 3600 RPM 3-phase 215JP Frame 208-230/400V ODP Vertical Close-Coupled Fire Pump Motor
FF15E1DV Nidec 15 hp 3600 RPM 3-phase 215JP Frame 208-230/400V ODP Vertical Close-Coupled Fire Pump Motor

Nidec

FF15E1DV Nidec 15 hp 3600 RPM 3-phase 215JP Frame 208-230/400V ODP Vertical Close-Coupled Fire Pump Motor

(No reviews) Write a Review
$1,956.15
$1,746.62
SKU FF15E1DV
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/400V
Horsepower 15 HP
RPM 3600
Phase Three Phase
Frame 215JP
Enclosure ODP
Hertz 60 Hz
Amperage 36.0/18.1 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 15 HP 3600 RPM, 41.0-36.0/18.1 amps, 208-230/400V 60hz. 3 Phase.
  • NEMA 215JP Rolled Steel Frame, JP stainless steel shaft
  • 1.15 Service Factor, Class F insulation
  • Reversible Rotation,
  • Face Mount, No Base, Ball Bearings

Meets NFPA 20 standards. Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drip Proof, FB77

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/400V
Horsepower 15 HP
RPM 3600
Phase Three Phase
Frame 215JP
Enclosure ODP
Hertz 60 Hz
Amperage 36.0/18.1 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
