FF20E1XV Nidec 20 hp 3600 RPM 3-phase 254JP Frame 200/400V ODP Vertical Close-Coupled Fire Pump Motor
FF20E1XV Nidec 20 hp 3600 RPM 3-phase 254JP Frame 200/400V ODP Vertical Close-Coupled Fire Pump Motor
FF20E1XV Nidec 20 hp 3600 RPM 3-phase 254JP Frame 200/400V ODP Vertical Close-Coupled Fire Pump Motor
FF20E1XV Nidec 20 hp 3600 RPM 3-phase 254JP Frame 200/400V ODP Vertical Close-Coupled Fire Pump Motor

Nidec

FF20E1XV Nidec 20 hp 3600 RPM 3-phase 254JP Frame 200/400V ODP Vertical Close-Coupled Fire Pump Motor

(No reviews) Write a Review
$2,435.70
$2,174.54
SKU FF20E1XV
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200/400V
Horsepower 20 HP
RPM 3600
Phase Three Phase
Frame 254JP
Enclosure ODP
Hertz 60 Hz
Amperage 54.0/27.1 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 20 HP 3600 RPM, 54.0/27.1 amps, 200/400V 60 Hz, 3 Phase.
  • NEMA 254JP Rolled Steel Frame, JP stainless steel shaft
  • 1.15 Service Factor, Class F insulation
  • Reversible Rotation,
  • Face Mount, No Base, Ball Bearings,

Meets NFPA 20 standards. Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drip Proof, HC52

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200/400V
Horsepower 20 HP
RPM 3600
Phase Three Phase
Frame 254JP
Enclosure ODP
Hertz 60 Hz
Amperage 54.0/27.1 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
