FX32BK001 | 1 1/2 HP 3600 RPM 56HC 208-230/460V 3 Phase ODP, FLEX-IN-1 Marathon Electric Motor

FX32BK001 | 1 1/2 HP 3600 RPM 56HC 208-230/460V 3 Phase ODP, FLEX-IN-1 Marathon Electric Motor

The Marathon FLEX-IN-1™ FX32BK001 is a versatile 1 1/2 HP, 3600 RPM electric motor designed to replace hundreds of discontinued or out-of-stock brand name motors. Ideal for industrial applications, it fits standard 56 frame mounts with or without C-face, offering a cost-effective and reliable replacement solution.

Key Specifications

• Horsepower: 1 1/2 HP
• RPM: 3600
• Voltage: 208-230/460 V
• Amperage: 4.2-4.0/2.0 A
• Enclosure: TEFC (Totally Enclosed Fan Cooled)
• Frame / Diameter: 56HC with removable mounting base
• Rotation: 3 Phase
• Bearings: Double-sealed ball bearings

Product Features & Fitment

This motor features Marathon’s patent-pending FLEX-IN-1™ multi-mount design with a repositionable bolt-on base and C-face, allowing rapid reconfiguration of the conduit box and mounting positions. The conduit box is rotatable 180° with 7/8” and 1-1/8” knockouts on all sides, and the fan guard can be rotated in 90° increments to align with base repositioning.

Additional features include hole plugs for repositioning the base to NEMA F-2 and F-3 conduit box locations, a conduit box cover gasket meeting IP44 or better enclosure ratings, and cast-in end frame markings for F-1, F-2, and F-3 base locations. The motor supports mounting for NEMA 56, 56H, 143T, and 145T frames, making it a flexible and easy-to-install replacement motor for a wide range of industrial equipment.
