G638 Nidec 1/2 hp 1800 RPM 56C Frame (Rigid Base) 90V TEFC DC Permanent Magnet Motor

G638 Nidec 1/2 hp 1800 RPM 56C Frame (Rigid Base) 90V TEFC DC Permanent Magnet Motor

SKU:
G638
Weight:
23.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $857.00
Now: $765.00
Adding to cart… The item has been added
  • 1/2 hp 1800 RPM, 5.0 amps 90 Volts DC
  • NEMA 56C Rolled Steel Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • 20:1 Constant Speed Range
  • Removable Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For general on industrial equipment including fans, pumps, and compressors. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. G638

!
