Century Electric Motor
DC129 Marathon 3/4 hp DC Perm. Magnet 56C Frame C Face TEFC 2500 RPM (rigid base) 90V Marathon Motor
(No reviews)
Write a Review
Write a Review
Century Electric Motor
DC129 Marathon 3/4 hp DC Perm. Magnet 56C Frame C Face TEFC 2500 RPM (rigid base) 90V Marathon Motor
$910.80
$771.88
SKU
DC129
UPC
7.87E+11
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage
90V
Horsepower
3/4 HP
RPM
2500
Frame
56C
Enclosure
TEFC
Amperage
7.6 Amps
Bearings
Ball Bearings
Service Factor
1.0
Insulation Class
Class H
Mounting
C-Face
- 3/4 hp 2500 RPM, 7.6 amps 90 Volts DC current.
- NEMA 56C frame, C-face, Keyed Shaft 5/8" Diameter x 1 7/8"
- Service Factor: 1.0, Overload protection = None
- Rigid Base, Reversible, Ball Bearings, Class H Insulation
- 1 Year Manufacture Warranty
Controller rated DC electric motor with a C-face mount. 20:1 constant torque. Shaft has keyway. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. DC129
| Voltage | 90V |
|---|---|
| Horsepower | 3/4 HP |
| RPM | 2500 |
| Frame | 56C |
| Enclosure | TEFC |
| Amperage | 7.6 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.0 |
| Insulation Class | Class H |
| Mounting | C-Face |
