GP0054G TECO Westinghose SGR 5 hp 1800 RPM 182/184TC Frame 230/460V TEFC 3-Phase Motor

SKU:
GP0054G
Weight:
94.00 LBS
Shipping:
Calculated at Checkout
$539.10
Adding to cart… The item has been added

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 5 hp 1800 RPM, 13.1/6.6 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 182/184TC Frame, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Rolled Steel Frame, Enclosure: Totally Enclosed Fan Cooled (IP44)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Motor comes with Shaft Grounding Rings (SGR) to protect bearings from excessive currents. Applications: Fans & Blowers, Pumps, Compressors, Mixers, Conveyors, HVAC Equipment
