HD5P3H Nidec 5 hp 1200 RPM 215T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor
HD5P3H Nidec 5 hp 1200 RPM 215T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor
HD5P3H Nidec 5 hp 1200 RPM 215T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor
HD5P3H Nidec 5 hp 1200 RPM 215T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor

Nidec

HD5P3H Nidec 5 hp 1200 RPM 215T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$997.05
$889.99
SKU HD5P3H
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200/208V
Horsepower 5 HP
RPM 1200
Phase Three Phase
Frame 215T
Enclosure TEFC
Hertz 60 Hz
Amperage 16.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 5 hp 1200 RPM, 16.4-16.3 amps 208-230 Volts 60 Hz Three Phase Motor
  • NEMA 215T Cast Iron frame Keyed Shaft 1 3/8" Diameter x 3 3/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Hostile duty motor can be used for many applications requiring a three phase electric motor. Inverter Duty. Self-certified Class 1, Division 2, Groups A, B, C, D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. GE12

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200/208V
Horsepower 5 HP
RPM 1200
Phase Three Phase
Frame 215T
Enclosure TEFC
Hertz 60 Hz
Amperage 16.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
