HO40V2BLF Nidec 40 hp 1800 RPM 230/460V 3-phase 324TPH Frame Inverter-Duty Vertical Holloshaft Motor

HO40V2BLF Nidec 40 hp 1800 RPM 230/460V 3-phase 324TPH Frame Inverter-Duty Vertical Holloshaft Motor

SKU:
HO40V2BLF
Availability:
Please email for availability
Weight:
308.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $6,001.00
Now: $5,358.20

CURRENTLY OUT OF STOCK

  • 40 HP 1800 RPM, 97.0/49.0 amps, 230/460V 60 Hz. 3-Phase Inverter Duty
  • NEMA 324TPH Frame, RUSI type, 12.0" Dia. Base
  • 1.15 Service Factor, Class F insulation, Thermal Protection: None
  • Non-Reversible Ratchet Rotation, Weather Protected Enclosure
  • P-Base Mounting, Ball Bearings, High Thrust
  • Coupler: Non-Reverse Ratchet (NRR), Height - 28 7/32", Diameter - 1 1/4" , Keyway 1/4"

Vertical pump motor for use on turbine, mix flow, and propeller pumps. 1 Year Manufacture Warranty. HF94

!
