JS0502-2V US Motors 1/2 hp 3450 RPM ODP 48Y 115/230V Jet (Non-Pool) Pump Motor
JS0502-2V US Motors 1/2 hp 3450 RPM ODP 48Y 115/230V Jet (Non-Pool) Pump Motor
JS0502-2V US Motors 1/2 hp 3450 RPM ODP 48Y 115/230V Jet (Non-Pool) Pump Motor
JS0502-2V US Motors 1/2 hp 3450 RPM ODP 48Y 115/230V Jet (Non-Pool) Pump Motor

US Motors

JS0502-2V US Motors 1/2 hp 3450 RPM ODP 48Y 115/230V Jet (Non-Pool) Pump Motor

(No reviews) Write a Review
$297.85
$265.54
SKU JS0502-2V
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1/2 HP
RPM 3450
Frame 48Y
Enclosure ODP
Hertz 60 Hz
Amperage 8.4/4.2 Amps
Bearings Ball Bearings
Insulation Class Class B
Rotation Counter-Clockwise
Mounting Flange
Adding to cart… The item has been added
Description
  • 1/2 HP 3450 RPM 48Y, 8.4/4.2 amps, 115/230V 60hz. Capacitor Start
  • NEMA 48Y frame (no base), 1/2" diameter threaded stainless steel shaft
  • 1.9 Service Factor, Auto Overload Thermal Protection, Class B insulation
  • Non-Reversible, CCW Rotation facing shaft
  • Square Flange Mount, Ball Bearings, Open Drip Proof (ODP)

Two compartments for easy maintenance. Wiring diagram on motor name plate. 1 year warranty. Model C055JTL2010013J

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1/2 HP
RPM 3450
Frame 48Y
Enclosure ODP
Hertz 60 Hz
Amperage 8.4/4.2 Amps
Bearings Ball Bearings
Insulation Class Class B
Rotation Counter-Clockwise
Mounting Flange
!
