K3102 Three Phase C-Face Jet Pump 1 HP

K3102 Three Phase C-Face Jet Pump 1 HP

The K3102 is a durable 1 HP three-phase jet pump motor designed for industrial and HVAC applications requiring reliable performance and easy integration. It serves as a direct replacement for various cross-referenced models, ensuring compatibility and efficient operation in pumping systems.

Key Specifications

• Horsepower: 1 HP
• RPM: 3450
• Voltage: 208-230/460 V
• Amperage: 4.0/2.0 A
• Enclosure: Open Drip Proof
• Frame / Diameter: 56C Frame
• Shaft Dimensions: Keyed shaft, stainless steel threaded
• Bearings: Double shielded ball bearings, lubricated for life

Product Features & Fitment

This motor features a NEMA 56C C-Face mounting bracket with die-cast corrosion-resistant aluminum end frames, precisely machined for maximum concentricity and minimal runout. The stator assembly is press-fitted into a rolled steel main frame, enhancing durability. The motor includes an internal junction box under the canopy, eliminating the need for an external junction box, and a 1/2" x 14 thread tapped opening for conduit fitting.

Designed for continuous duty at 40°C ambient temperature and 60 Hz operation, the motor comes with a horizontal canopy standard but can be easily converted to vertical operation using an optional vertical canopy accessory. Ball bearings are selected for quiet operation and are resistant to moisture and heat.

Cross Reference

• s:312P766 314P575 P48L2DA1 P48L2DA1A3 P48L2DA1A4 P56L2D1 H511 H513 CD10FL1P 14834 K220 P004 V56T34D5313 93286
