3900-0361-888 Marley Electric Motor 1/20 hp 1550 RPM 208-230/480V

3900-0361-888 Marley Electric Motor 1/20 hp 1550 RPM 208-230/480V

This Marley electric motor delivers reliable performance with 1/20 horsepower and 1550 RPM, designed for HVAC and industrial applications. It is compatible with Emerson (Chromalox) models CA2H013, CA2H015, CA2H021, CA2G192, and CA2G192N, and serves as a replacement for Century 657 motors.

Key Specifications

• Horsepower: 1/20 hp
• RPM: 1550
• Voltage: 208-230/480 V
• Amperage: 1.0 / 0.5 A
• Frame / Diameter: 4-5/16" diameter
• Shaft Dimensions: 5/16" diameter x 3-1/2" length
• Rotation: CCWSE (Counterclockwise Shaft End)

Product Features & Fitment

This single-phase motor features specific wiring connections for both 208-230V and 480V configurations. For 208-230V, the orange wire (appearing brown) is Line One, blue and white wires are tied together as Line Two, and black and red wires are capped off. For 480V, the orange wire is Line One, white is Line Two, black is unused and taped, while red and blue are capped off. Proper wiring ensures optimal motor performance and safety during installation.

Warranty

1 Year Manufacturer Warranty
