NP7/52G TECO-Westinghouse 7 1/2 hp 3600 RPM 213T 230/460V TEFC Severe Duty SGR 3-Ph Motor
The TECO-Westinghouse NP7/52G is a premium NEMA electric motor designed for industrial applications requiring reliable, high-performance operation. It replaces standard motors in severe duty environments, providing robust power and inverter compatibility for variable speed control.
Key Specifications
- Horsepower: 7 1/2 hp
- RPM: 3600
- Voltage: 230/460 V
- Amperage: 17.3/8.67 A
- Enclosure: Totally Enclosed Fan Cooled (TEFC), IP56
- Frame / Diameter: NEMA 213T Frame
- Shaft Dimensions: 3 3/8" x 1 3/8" Diameter, Keyed Shaft
- Rotation: Reversible
- Bearings: Ball Bearings
Product Features & Fitment
This motor features a cast iron frame with a rigid base for stable mounting and durability in demanding environments. It includes an SGR bearing protection ring to divert harmful voltages away from the bearings, making it suitable for electrically risky conditions. The motor is rated for inverter duty with a speed range of 20:1 for variable torque and 10:1 for constant torque, complying with NEMA MG-1 Part 31.4.4.2 standards.
Warranty
1 Year Manufacturer Warranty
