O213 Marathon 1/2 hp (1 speed) 115/208-230V 3450 RPM ODP 56C Frame Cap Start Oil Burner Motor

O213 Marathon 1/2 hp (1 speed) 115/208-230V 3450 RPM ODP 56C Frame Cap Start Oil Burner Motor

This Marathon 1/2 horsepower motor is designed as a direct replacement for oil burner furnace motors. It operates at 3450 RPM with a single speed and is suitable for applications requiring a capacitor start motor with an open drip proof enclosure.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 3450
• Voltage: 115/208-230 V
• Amperage: 7.4/3.5-3.7 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 56C Frame
• Shaft Dimensions: 2" length x 5/8" diameter
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a capacitor start design with a manual thermal protection system and a service factor of 1.6. It includes a 56C frame with a shaft sized for oil burner mounts, ensuring compatibility with existing furnace setups. The motor is built with Class B insulation and is suitable for direct replacement in oil burning furnace applications.

Cross Reference

• motors in oil burning furnaces. ODP = Open Drip Proof, 056C34D2099

Warranty

1 Year Manufacturer Warranty
