Q0606 TECO-Westinghouse 60 HP 1200 RPM 404T 230/460/796V ODP 3-Phase Oil Well Pump Motor
Q0606 TECO-Westinghouse 60 HP 1200 RPM 404T 230/460/796V ODP 3-Phase Oil Well Pump Motor
Q0606 TECO-Westinghouse 60 HP 1200 RPM 404T 230/460/796V ODP 3-Phase Oil Well Pump Motor
Q0606 TECO-Westinghouse 60 HP 1200 RPM 404T 230/460/796V ODP 3-Phase Oil Well Pump Motor

TECO WESTINGHOUSE

Q0606 TECO-Westinghouse 60 HP 1200 RPM 404T 230/460/796V ODP 3-Phase Oil Well Pump Motor

(No reviews) Write a Review
$5,854.52
SKU Q0606
Shipping Calculated at Checkout
Voltage 230/460/796V
Horsepower 60 HP
RPM 1200
Phase Three Phase
Frame 404T
Enclosure ODP
Hertz 60 Hz
Amperage 70.0/40.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 60 hp 1200 RPM, 140/70.0/40.3 amps 230/460/796 Volts 60 Hz. Three Phase
  • NEMA 404T Frame, 7 3/4 x 2 7/8" Dia. Keyed Shaft
  • Cast Iron Frame, Open Drip Proof
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Rodent Screens, 5% Minimum Slip
  • 1 Year Manufacture Warranty

Oil well pump motor for use on oil pumps. Also good for any application requiring NEMA Design D torques.

Specifications
Voltage 230/460/796V
Horsepower 60 HP
RPM 1200
Phase Three Phase
Frame 404T
Enclosure ODP
Hertz 60 Hz
Amperage 70.0/40.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
