R2-R419 Rotom 1/8 hp 3000 RPM 115/230 Volts 1-Speed CW 3.3" Diameter PSC Blower Motor

SKU:: R2-R419
UPC:
Weight:: 10.00 LBS
Width:: 10.00 (in)
Height:: 8.00 (in)
Depth:: 5.00 (in)
Shipping:: Free Shipping
Voltage:: 115/230V
Horsepower:: 1/8 HP
RPM:: 3000
Enclosure:: TEAO
Hertz:: 60 Hz
Type:: PSC (Permanent Split Capacitor)
Amperage:: 1.8 Amps
Bearings:: Ball Bearings
Speeds:: 1-Speed
Mounting:: Stud

Current Stock:

Was: $218.50

Now: $139.95

Quantity:

Adding to cart… The item has been added

Description
Literature

R2-R419 Rotom 1/8 hp 3000 RPM 115/230 Volts 1-Speed CW 3.3" Diameter PSC Blower Motor

The R2-R419 is a 1/8 horsepower, single-speed blower motor designed for HVAC and industrial applications. It serves as a direct replacement for models such as Fasco D219 and 71622886, providing reliable performance in air-moving equipment.

Key Specifications

Horsepower: 1/8 hp
RPM: 3000
Voltage: 115/230 Volts, 60 Hz
Amperage: 1.8 amps
Enclosure: Totally Enclosed Air Over (TEAO)
Frame / Diameter: 3.3" diameter
Shaft Dimensions: 5/16" diameter x 1.175" length with flat
Rotation: Reversible
Bearings: Ball bearing

Product Features & Fitment

This PSC motor includes a 4 MFD capacitor and comes pre-wired for easy installation. It supports both belly band or stud mounting with a bolt circle diameter of 4.62", ensuring versatile fitment in various blower assemblies.
