R322B Marathon | 3 hp 2.2 kw 1800 RPM 100L Frame 230/460V Marathon Electric Metric Motor

R322B Marathon | 3 hp 2.2 kw 1800 RPM 100L Frame 230/460V Marathon Electric Metric Motor

SKU:
R322B
Weight:
107.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $785.80
Now: $683.00
Adding to cart… The item has been added
  • 3 hp 2.2 kw 1800 RPM, 7.8/3.9 amps 230/460 Volts Three Phase Motor
  • IEC 100L Frame keyed shaft 28mm x 60mm
  • TEFC - IP55 Weatherproof Enclosure - Conduit Box Location = F3 (top)
  • Inverter Rated Insulation System (IRIS) - Service Factor: 1.15
  • TEFC = Totally Enclosed Fan Cooled; Class F Insulation
  • 1 Year Manufacture Warranty

12-Lead Delta Windings (160MD frame & larger) for across the line or wye-delta starts. Class F insulation. Oil seals on both drive end and non drive end. Drilled and tapped shaft. CSA file #LR33543, UL file #E57948,Conformite European.

100LTFC6526, TCA2P22AE211GAA009 Replaces Leeson C112T11FZ21A, 193301.60
Replaces Marathon R322A

!
