108708100EQF Stearns Brake Assembly
The 108708100EQF Stearns Brake Assembly is a solenoid-actuated, spring-set disc brake designed for industrial motor applications requiring reliable stopping torque. It replaces standard NEMA 2 brakes and is ideal for horizontal mounting on 3-phase motors operating at 208-230/460 volts.
Key Specifications
- Voltage: 208-230/460 V, 3-Phase
- Enclosure: IP23 (NEMA 2)
- Shaft Dimensions: 1-1/8" Hub Bore
- Torque: 105 ft-lb
- Rotation: Horizontal Mount Only
- Maximum Speed: 5000 RPM
Product Features & Fitment
This brake features manually adjustable torque and manual wear adjustment with a side manual release lever that automatically resets. It includes a Class B coil insulation and a stamped steel housing with double C-face mounting. The lead wire length is 24 inches. For vertical mounting, additional parts are required; please contact us to order the appropriate configuration. Due to the wide variety of brake combinations, if your specific brake is not listed, reach out for assistance. Lead time for shipment is approximately one week.
