T13S2GCR Nidec 1/3 hp 1800 RPM 56C Frame (No Base) 575V TEFC 3-Phase Electric Motor
T13S2GCR Nidec 1/3 hp 1800 RPM 56C Frame (No Base) 575V TEFC 3-Phase Electric Motor
T13S2GCR Nidec 1/3 hp 1800 RPM 56C Frame (No Base) 575V TEFC 3-Phase Electric Motor
T13S2GCR Nidec 1/3 hp 1800 RPM 56C Frame (No Base) 575V TEFC 3-Phase Electric Motor

Nidec

T13S2GCR Nidec 1/3 hp 1800 RPM 56C Frame (No Base) 575V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$249.55
$223.09
SKU T13S2GCR
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 1/3 HP
RPM 1800
Phase Three Phase
Frame 56C
Enclosure TEFC
Hertz 60 Hz
Amperage 0.59 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1/3 hp 1800 RPM, 0.59 amps 575 Volts 60 Hz Three Phase Motor
  • NEMA 56C frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C- Face motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. P063GHS4583015B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 1/3 HP
RPM 1800
Phase Three Phase
Frame 56C
Enclosure TEFC
Hertz 60 Hz
Amperage 0.59 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
!
