T1C2P18Z Nidec 1 hp 1800 RPM 115/230V 182 Frame (Rigid Base) 1-Speed TEFC Cap Start Motor

    1 hp 1800 RPM, 13.8/6.9 amps 115/230V Volts 60 Hz Capacitor Start Motor
    NEMA 182 Frame, Rolled Steel with Cast Aluminum End Bells, Keyed Shaft 7/8" Diameter x 2 3/4"
    Service Factor: 1.0 Overload protection = None
    Rigid Mount, Ball Bearings, Class F Insulation, Reversible
    1 Year Manufacture Warranty

For used on air compressors, pumps, and conveyor requiring high starting torque. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. AF72
