T2C2P18 Nidec 2 hp 1800 RPM 115/230V 182T Frame (Rigid Base) 1-Speed TEFC Cap Start Motor

T2C2P18 Nidec 2 hp 1800 RPM 115/230V 182T Frame (Rigid Base) 1-Speed TEFC Cap Start Motor

SKU:
T2C2P18
Weight:
50.00 LBS
Width:
20.00 (in)
Height:
13.00 (in)
Depth:
10.00 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
115/230V
Horsepower:
2 HP
RPM:
1800
Frame:
182T
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
23.6/11.8 Amps
Bearings:
Ball Bearings
Speeds:
1-Speed
Service Factor:
1.0
Insulation Class:
Class F
Mounting:
Rigid Base
Was: $985.55
Now: $879.75
Adding to cart… The item has been added
  • 2 hp 1800 RPM, 23.6/11.8 amps 115/230V Volts 60 Hz Capacitor Start Motor
  • NEMA 182T Frame, Rolled Steel with Cast Aluminum End Bells, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.0 Overload protection = None
  • Rigid Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For used on air compressors, pumps, and conveyor requiring high starting torque. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. G527

!
