T32C2P18Z Nidec 1 1/2 hp 1800 RPM 115/230V 184 Frame (Rigid Base) 1-Speed TEFC Cap Start Motor
T32C2P18Z Nidec 1 1/2 hp 1800 RPM 115/230V 184 Frame (Rigid Base) 1-Speed TEFC Cap Start Motor
T32C2P18Z Nidec 1 1/2 hp 1800 RPM 115/230V 184 Frame (Rigid Base) 1-Speed TEFC Cap Start Motor
T32C2P18Z Nidec 1 1/2 hp 1800 RPM 115/230V 184 Frame (Rigid Base) 1-Speed TEFC Cap Start Motor

Nidec

T32C2P18Z Nidec 1 1/2 hp 1800 RPM 115/230V 184 Frame (Rigid Base) 1-Speed TEFC Cap Start Motor

(No reviews) Write a Review
$1,304.10
$1,164.84
SKU T32C2P18Z
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1/2 HP
RPM 1800
Frame 184
Enclosure TEFC
Hertz 60 Hz
Amperage 18.4/9.2 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.0
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1 1/2 hp 1800 RPM, 18.4/9.2 amps 115/230V Volts 60 Hz Capacitor Start Motor
  • NEMA 184 Frame, Rolled Steel with Cast Aluminum End Bells, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.0 Overload protection = Manual
  • Rigid Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For used on air compressors, pumps, and conveyor requiring high starting torque. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. T32C2P18Z

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1/2 HP
RPM 1800
Frame 184
Enclosure TEFC
Hertz 60 Hz
Amperage 18.4/9.2 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.0
Insulation Class Class F
Mounting Rigid Base
!
