U12P2DCR Nidec 1/2 hp 1800 RPM 56C Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor
U12P2DCR Nidec 1/2 hp 1800 RPM 56C Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor
U12P2DCR Nidec 1/2 hp 1800 RPM 56C Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor
U12P2DCR Nidec 1/2 hp 1800 RPM 56C Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor

Nidec

U12P2DCR Nidec 1/2 hp 1800 RPM 56C Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$354.20
$316.25
SKU U12P2DCR
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 56C
Enclosure TEFC
Hertz 60/50 Hz
Amperage 1.8/0.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1/2 hp 1800 RPM, 1.8-1.8/0.9 amps 208-230/460 Volts 60/50 Hz Three Phase Motor
  • NEMA 56C frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C- Face motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. DS64

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 56C
Enclosure TEFC
Hertz 60/50 Hz
Amperage 1.8/0.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
!
