U15P1DFC Nidec 15 hp 3600 RPM 215TC Frame 208-230/460V TEFC 3-Phase Electric Motor

U15P1DFC Nidec 15 hp 3600 RPM 215TC Frame 208-230/460V TEFC 3-Phase Electric Motor

This Nidec 15 horsepower, 3600 RPM three-phase electric motor is designed for general-purpose industrial applications. It serves as a reliable replacement motor compatible with equipment requiring a NEMA 215TC frame and TEFC enclosure.

Key Specifications

• Horsepower: 15 hp
• RPM: 3600
• Voltage: 208-230/460 V
• Amperage: 40.0-35.0/17.4 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: 215TC
• Shaft Dimensions: 1 1/8" Diameter x 2 1/4" Length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base mount and a keyed shaft for secure installation. It includes Class F insulation and a service factor of 1.25, suitable for demanding industrial environments. Wiring diagrams are provided on the motor nameplate to assist with proper electrical connections.

Warranty

1 Year Manufacturer Warranty
