sale
Nidec
U20P1G Nidec 20 hp 3600 RPM 256T Frame 575V TEFC 3-Phase Electric Motor
(No reviews)
Write a Review
Write a Review
Nidec
U20P1G Nidec 20 hp 3600 RPM 256T Frame 575V TEFC 3-Phase Electric Motor
$2,164.30
$1,932.58
SKU
U20P1G
Shipping
Calculated at Checkout
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
LIMITED TIME DISCOUNT
Voltage
575V
Horsepower
20 HP
RPM
3600
Phase
Three Phase
Frame
256T
Enclosure
TEFC
Hertz
60 Hz
Amperage
18.5 Amps
Bearings
Ball Bearings
Service Factor
1.25
Insulation Class
Class F
Mounting
Rigid Base
- 20 hp 3600 RPM, 18.5 amps 575 Volts 60 Hz Three Phase Motor
- NEMA 256T frame Keyed Shaft 1 5/8" Diameter x 4"
- Service Factor: 1.25, Overload protection = None
- Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
- 1 Year Manufacture Warranty
General purpose motor can be used for many applications requiring a three phase electric motor. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. DY77
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | LIMITED TIME DISCOUNT |
| Voltage | 575V |
| Horsepower | 20 HP |
| RPM | 3600 |
| Phase | Three Phase |
| Frame | 256T |
| Enclosure | TEFC |
| Hertz | 60 Hz |
| Amperage | 18.5 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.25 |
| Insulation Class | Class F |
| Mounting | Rigid Base |
