U20V1B Nidec 20 hp 3600 RPM 256T (Rigid Base) 230/460V TEFC Inverter-Duty 3-Phase Motor

SKU:
U20V1B
Weight:
230.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $1,910.00
Now: $1,705.30
Adding to cart… The item has been added
  • 20 hp 3600 RPM, 46/23.1 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 256T Extruded Aluminum Frame with Cast Aluminum End Bells, Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Speed controllable motor for material handling, cranes and machine tools. 5:1 speed range at constant torque. NEMA design B. Brake provisions. Wiring diagram on motor name plate. TEFC = Totally-Enclosed Fan-Cooled. HD44
