U30P2DS Nidec 30 hp 1800 RPM 286TS Frame 208-230/460V TEFC 3-Phase Electric Motor
U30P2DS Nidec 30 hp 1800 RPM 286TS Frame 208-230/460V TEFC 3-Phase Electric Motor
U30P2DS Nidec 30 hp 1800 RPM 286TS Frame 208-230/460V TEFC 3-Phase Electric Motor
U30P2DS Nidec 30 hp 1800 RPM 286TS Frame 208-230/460V TEFC 3-Phase Electric Motor

Nidec

U30P2DS Nidec 30 hp 1800 RPM 286TS Frame 208-230/460V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$2,711.70
$2,421.44
SKU U30P2DS
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 30 HP
RPM 1800
Phase Three Phase
Frame 286TS
Enclosure TEFC
Hertz 60 Hz
Amperage 70/35 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 30 hp 1800 RPM, 78-70/35 amps 208/230/460 Volts 60 Hz Three Phase Motor
  • NEMA 286TS frame Keyed Shaft 1 5/8" Diameter x 3 1/4"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. CN08

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 30 HP
RPM 1800
Phase Three Phase
Frame 286TS
Enclosure TEFC
Hertz 60 Hz
Amperage 70/35 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
