sale
U32P2DCR Nidec 1 1/2 hp 1800 RPM 143TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor
U32P2DCR Nidec 1 1/2 hp 1800 RPM 143TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor
U32P2DCR Nidec 1 1/2 hp 1800 RPM 143TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor
U32P2DCR Nidec 1 1/2 hp 1800 RPM 143TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor

Nidec

U32P2DCR Nidec 1 1/2 hp 1800 RPM 143TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$500.25
$409.95
SKU U32P2DCR
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 143TC
Enclosure TEFC
Hertz 50/60 Hz
Amperage 4.3/2.1 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1 1/2 hp 1800 RPM, 4.5-4.3/2.1 amps 208-230/460 Volts 50/60 Hz Three Phase Motor
  • NEMA 145TC frame Keyed Shaft 7/8" Diameter x 2 1/8"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C- Face motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. FN29

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 143TC
Enclosure TEFC
Hertz 50/60 Hz
Amperage 4.3/2.1 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
