U3P4D Nidec 3 hp 900 RPM 215T Frame 208-230/460V TEFC 3-Phase Electric Motor
U3P4D Nidec 3 hp 900 RPM 215T Frame 208-230/460V TEFC 3-Phase Electric Motor
U3P4D Nidec 3 hp 900 RPM 215T Frame 208-230/460V TEFC 3-Phase Electric Motor
U3P4D Nidec 3 hp 900 RPM 215T Frame 208-230/460V TEFC 3-Phase Electric Motor

Nidec

U3P4D Nidec 3 hp 900 RPM 215T Frame 208-230/460V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$1,454.75
$1,298.81
SKU U3P4D
Availability Subject to Availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 900
Phase Three Phase
Frame 215T
Enclosure TEFC
Hertz 50/60 Hz
Amperage 10.3/5.2 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 3 hp 900 RPM, 10.6-10.3/5.2 amps 208-230/460 Volts 50/60 Hz Three Phase Motor
  • NEMA 215T frame Keyed Shaft 1 3/8" Diameter x 3 1/2"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. FR04

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 900
Phase Three Phase
Frame 215T
Enclosure TEFC
Hertz 50/60 Hz
Amperage 10.3/5.2 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
