U5P1H Nidec 5 hp 3600 RPM 184T Frame 200V TEFC 3-Phase Electric Motor
U5P1H Nidec 5 hp 3600 RPM 184T Frame 200V TEFC 3-Phase Electric Motor
U5P1H Nidec 5 hp 3600 RPM 184T Frame 200V TEFC 3-Phase Electric Motor
U5P1H Nidec 5 hp 3600 RPM 184T Frame 200V TEFC 3-Phase Electric Motor

Nidec

U5P1H Nidec 5 hp 3600 RPM 184T Frame 200V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$901.60
$804.89
SKU U5P1H
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 5 HP
RPM 3600
Phase Three Phase
Frame 184T
Enclosure TEFC
Hertz 50/60 Hz
Amperage 14.0 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 5 hp 3600 RPM, 14.0 amps 200 Volts 50/60 Hz Three Phase Motor
  • NEMA 184T frame Keyed Shaft 1 1/8" Diameter x 2 1/4"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. DA68

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 5 HP
RPM 3600
Phase Three Phase
Frame 184T
Enclosure TEFC
Hertz 50/60 Hz
Amperage 14.0 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
