UJ10P1DJ US Motors 10 hp 3600 RPM 3-phase 213TCZ Frame 208-230/460V Close-Coupled Pump Motor
UJ10P1DJ US Motors 10 hp 3600 RPM 3-phase 213TCZ Frame 208-230/460V Close-Coupled Pump Motor
UJ10P1DJ US Motors 10 hp 3600 RPM 3-phase 213TCZ Frame 208-230/460V Close-Coupled Pump Motor
UJ10P1DJ US Motors 10 hp 3600 RPM 3-phase 213TCZ Frame 208-230/460V Close-Coupled Pump Motor

US Motors

UJ10P1DJ US Motors 10 hp 3600 RPM 3-phase 213TCZ Frame 208-230/460V Close-Coupled Pump Motor

(No reviews) Write a Review
$1,409.90
$1,258.45
SKU UJ10P1DJ
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 3600
Phase Three Phase
Frame 213TCZ
Enclosure TEFC
Hertz 60 Hz
Amperage 23.5/11.7 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 10 HP 3600 RPM, 26.4-23.5/11.7 amps, 208-230/460V 60hz. 3 Phase.
  • NEMA 213TCZ Cast Aluminum Frame, Special Westcoast stainless steel shaft
  • 1.25 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Totally Enclosed Fan Cooled,
  • Rigid Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. TEFC = Totally Enclosed Fan Cooled, Proof, FL55

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 3600
Phase Three Phase
Frame 213TCZ
Enclosure TEFC
Hertz 60 Hz
Amperage 23.5/11.7 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
!
