UJ20P1DM US Motors 20 hp 3600 RPM 3-phase 256JM Frame 208-230/460V Close-Coupled Pump Motor
UJ20P1DM US Motors 20 hp 3600 RPM 3-phase 256JM Frame 208-230/460V Close-Coupled Pump Motor
UJ20P1DM US Motors 20 hp 3600 RPM 3-phase 256JM Frame 208-230/460V Close-Coupled Pump Motor
UJ20P1DM US Motors 20 hp 3600 RPM 3-phase 256JM Frame 208-230/460V Close-Coupled Pump Motor

US Motors

UJ20P1DM US Motors 20 hp 3600 RPM 3-phase 256JM Frame 208-230/460V Close-Coupled Pump Motor

(No reviews) Write a Review
$2,387.40
$1,963.95
SKU UJ20P1DM
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 20 HP
RPM 3600
Phase Three Phase
Frame 256JM
Enclosure TEFC
Hertz 60 Hz
Amperage 46.0/23.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 20 HP 3600 RPM, 51.0-46.0/23.0 amps, 208-230/460V 60hz. 3 Phase.
  • NEMA 256JM Cast Aluminum Frame, JM stainless steel shaft
  • 1.25 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Totally Enclosed Fan Cooled,
  • Removable Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. TEFC = Totally Enclosed Fan Cooled, Proof, FK50

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 20 HP
RPM 3600
Phase Three Phase
Frame 256JM
Enclosure TEFC
Hertz 60 Hz
Amperage 46.0/23.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
