UJ20P2DP US Motors 20 hp 1800 RPM 3-phase 256JP Frame 208-230/460V Close-Coupled Pump Motor

SKU:
UJ20P2DP
Availability:
Subject to availability
Weight:
230.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $1,953.80
Now: $1,898.40
  • 20 HP 1800 RPM, 53.0-47.0/23.5 amps, 208-230/460V 60hz. 3 Phase.
  • NEMA 256JP Cast Aluminum Frame, JP stainless steel shaft
  • 1.25 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Totally Enclosed Fan Cooled,
  • Rigid Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. TEFC = Totally Enclosed Fan Cooled, Proof, FL47
