UJ5P2DP US Motors 5 hp 1800 RPM 3-phase 184JP Frame 208-230/460V Close-Coupled Pump Motor

UJ5P2DP US Motors 5 hp 1800 RPM 3-phase 184JP Frame 208-230/460V Close-Coupled Pump Motor

This US Motors close-coupled pump motor delivers 5 horsepower with a 1800 RPM speed, designed for reliable operation in industrial pump applications. It replaces standard 3-phase motors requiring a 184JP frame and supports 208-230/460V power input.

Key Specifications

• Horsepower: 5 HP
• RPM: 1800
• Voltage: 208-230/460V, 60 Hz
• Amperage: 13.6-12.3/6.2 amps
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: NEMA 184JP Cast Aluminum Frame
• Shaft Dimensions: JP stainless steel shaft
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a rigid base and is designed for close-coupled pump installations, where the pump impeller mounts directly on the motor shaft. It includes a 1.25 service factor, auto overload thermal protection, and Class F insulation for enhanced durability and performance in demanding environments.

Warranty

1 Year Manufacturer Warranty
