VSP0154 TECO-Westinghouse 15 HP 1800 RPM 254VP 230/460V TEFC Vertical Solid Shaft 3-Ph Motor

SKU:
VSP0154
Weight:
309.00 LBS
Shipping:
Calculated at Checkout
$2,699.92
Adding to cart… The item has been added

TECO WESTINGHOUSE NEMA PREMIUM HIGH THRUST ELECTRIC MOTOR

  • 15 hp 1800 RPM, 36.4/18.2 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 254VP Frame, 1 1/8" Dia. x 2-3/4 Solid Keyed Shaft
  • Cast Iron Frame, Open Drip Proof (ODP)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • CCW Rotation Viewed From Top, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Vertical motor with "P" base and Weather Protected Type I (WPI) Enclosre. For use in fluid hangling systems, irrigation, fire-pumps, and deep well systems
