WD10P2D Nidec 10 hp 1800 RPM 215T Frame (Rigid Base) 208-230/460V TEFC Washdown 3-Phase Motor

WD10P2D Nidec 10 hp 1800 RPM 215T Frame (Rigid Base) 208-230/460V TEFC Washdown 3-Phase Motor

This Nidec WD10P2D motor is a 10 horsepower, 1800 RPM, three-phase industrial motor designed for washdown environments, commonly used in food processing applications requiring frequent cleaning. It replaces standard motors with enhanced durability and corrosion resistance features suitable for rigorous washdown conditions.

Key Specifications

• Horsepower: 10 hp
• RPM: 1800
• Voltage: 208-230/460 V
• Amperage: 26.5-23.9/11.9 A
• Enclosure: Totally-Enclosed Fan-Cooled (TEFC)
• Frame / Diameter: NEMA 215T Rolled Steel Frame
• Shaft Dimensions: Stainless Steel Keyed Shaft, 1 3/8" Diameter x 3 7/8" Length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a rigid base with a C-face mount for easy installation and compatibility with various industrial setups. Constructed with a rolled steel frame and cast aluminum end bells, it offers durability and corrosion resistance. The painted washdown design ensures suitability for environments requiring frequent cleaning, such as food processing plants. The wiring diagram is conveniently located on the motor nameplate for straightforward electrical connections.

Warranty

1 Year Manufacturer Warranty
