WDP10P2AC Nidec 10 hp 1800 RPM 215TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WDP10P2AC Nidec 10 hp 1800 RPM 215TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WDP10P2AC Nidec 10 hp 1800 RPM 215TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WDP10P2AC Nidec 10 hp 1800 RPM 215TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor

Nidec

WDP10P2AC Nidec 10 hp 1800 RPM 215TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor

(No reviews) Write a Review
$2,132.10
$1,903.60
SKU WDP10P2AC
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 1800
Phase Three Phase
Frame 215TC
Enclosure TEFC
Hertz 60 Hz
Amperage 23.8/11.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 10 hp 1800 RPM, 26.5-23.8/11.9 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 215TC Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Paint-Free wash-down motor for food and pharmaceutical applications. All stainless steel except for the side box. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. DD49

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 1800
Phase Three Phase
Frame 215TC
Enclosure TEFC
Hertz 60 Hz
Amperage 23.8/11.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
