WD3P3DC Nidec 3 hp 1200 RPM 213TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD3P3DC Nidec 3 hp 1200 RPM 213TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD3P3DC Nidec 3 hp 1200 RPM 213TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD3P3DC Nidec 3 hp 1200 RPM 213TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor

Nidec

WD3P3DC Nidec 3 hp 1200 RPM 213TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor

(No reviews) Write a Review
$1,815.85
$1,620.81
SKU WD3P3DC
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 1200
Phase Three Phase
Frame 213TC
Enclosure TEFC
Hertz 60 Hz
Amperage 8.3/4.2 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 3 hp 1200 RPM, 9.0-8.3/4.2 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 213TC Rolled Steel Frame, Keyed Shaft 1 3/8" Diameter x 3 3/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Easy cleaning painted wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. DX43

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 1200
Phase Three Phase
Frame 213TC
Enclosure TEFC
Hertz 60 Hz
Amperage 8.3/4.2 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
