WD2P3DC Nidec 2 hp 1200 RPM 184TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD2P3DC Nidec 2 hp 1200 RPM 184TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD2P3DC Nidec 2 hp 1200 RPM 184TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD2P3DC Nidec 2 hp 1200 RPM 184TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor

Nidec

WD2P3DC Nidec 2 hp 1200 RPM 184TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor

(No reviews) Write a Review
$1,573.20
$1,404.73
SKU WD2P3DC
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 2 HP
RPM 1200
Phase Three Phase
Frame 184TC
Enclosure TEFC
Hertz 60 Hz
Amperage 6.2/3.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 2 hp 1200 RPM, 6.4-6.2/3.1 amps  208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 184TC Rolled Steel Frame, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Easy cleaning painted wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. DX42

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 2 HP
RPM 1200
Phase Three Phase
Frame 184TC
Enclosure TEFC
Hertz 60 Hz
Amperage 6.2/3.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
